1000LPH RO System
KAI YUAN
1000LPH Reverse Osmosis Machine
Product Description
Reverse Osmosis System:
Our reverse osmosis water purification systems are designed to effectively purify water, ensuring it is clean and safe for various applications. The system comprises the following components:
Booster Pump: Enhances water pressure to optimize the purification process.
FRP Pre-treatment Tanks: Houses sand filters and activated carbon filters to remove sediment and impurities.
SS304 Cartridge Filter Housing: Provides a durable and corrosion-resistant structure for cartridge filters.
Chemical Dosing Systems: Adds necessary chemicals to treat the water, improving purification efficiency.
High-Pressure Pump: Applies pressure to force water through the reverse osmosis membrane.
FRP Membrane Pressure Vessel: Houses the membranes, withstands high pressure, and is made of strong, corrosion-resistant fiberglass.
4040 Membranes: The core component that filters out contaminants.
Control Panel and Touch Screen Control: Allows for monitoring and control of the system's operation, with both automatic and manual modes available.
Customization and Flexibility: The materials and parts used in our systems can be customized based on the raw water quality and specific customer requirements. Our touch screen panel offers a comprehensive view of the system flow diagram, enabling efficient monitoring and control.
Advanced Water Treatment Technologies: With our innovative water treatment technologies, you can manage the entire system effectively, ensuring optimal performance.
Purification Efficiency: The membranes in our reverse osmosis systems are designed to block small particles, viruses, and bacteria, resulting in very clean and safe water. The equipment effectively removes large particles, suspended matter, colloids, organic matter, taste, bacteria, viruses, heavy metal ions, and other harmful substances, as well as 99% of dissolved salts. The system achieves a desalination rate of 97% or higher, with the conductivity of the outlet water reaching ≤10μS/cm.
Capacity | 1000 L/H |
Rated power | 3.8 KW |
Voltage | 110V / 220V / 380V, 50Hz / 60Hz, Single phase / Three phase |
Desalination rate | ≥97% |
Water recovery rate | 50-75% |
Conductivity of raw water | ≤500μs |
Conductivity of pure water | ≤10μs |
Optional Components :
A. Regulating wheels B. PLC Touch Screen C. Two-stage RO system D. PH adjustment anti-scale E. Automatic cleaning system F. Auto or manual control valve G. U-PVC or stainless steel pipe H. UV sterilizer/Ozone Generator I. Dosing system/Water Softener J. PE or stainless steel raw/pure water tank K. FRP or stainless steel pre-treatment tank
Advantages | |
1 | RO Membrane use Vontron brand,Stable water quality and long service life |
2 | Brand CNP Pump,Stable power, not easy to damage |
3 | Runxin automatic backwashing valve,high precision control |
4 | SS pipe adopt 1side welding and 2 side molding ,so bacteria will not grow inside |
5 | One-key operation of the circuit box, no need for multiple operations, easy to use |
6 | Mitsubishi/Siemens PLC electric control,factory self-programming,stable system, lifetime after-sales service |
7 | Detection of various indicating instruments real-time monitoring of equipment and normal operation of water quality |
8 | Clear current circuit layout,Humanized corresponding wire label marking |
Flow meter / pressure guage
Security filter
Membrane shell
High-pressure pump
Before Buying Reverse osmosis System,you should know:
Source of Raw Water: Identify the type of water you will be treating. This could be:
The quality and composition of the raw water will significantly impact the system's design and performance.
Underground water (well water)
Tap water (municipal supply)
Other sources (river, lake, etc.)
Water Flow Rate: Determine the volume of water you need to process per hour. Common flow rates include:
The flow rate is crucial for selecting a system with the appropriate capacity to meet your demands without compromising on water quality.
500 liters per hour (L/H)
1000 L/H
Other specific rates based on your needs
Purpose of Purified Water: Clarify the intended use of the purified water. Common purposes include:
Direct drinking
Bottled water production
Industrial applications
Product Processing
Process: raw water tank(buyer supply)→ raw water pump→quartz sand filter →activated carbon filter→security filter→1st high pressure pump→1st ro system→2nd high pressure pump→2nd ro system→pure water tank(buyer provided)+UV sterilizer(ozone generator) +water supply point | ||||
Item | Commodity name | Description/Application | Model | Material |
1 | Raw water tank | ①To store raw water ②Buffering effect, (with peak water consumption, water shutdown stage) | 0.25m³~50m³ | ①PE ②Fiber Reinforced Plastic ③Stainless steel SUS-304 SUS-316 ④Carbon steel |
2 | Raw water pump | To provide pressure for the raw water pretreatment system (such as quartz sand filter, activated carbon filter, water softener, security filter, etc.). | GRUNDFOS CNP Lingxiao | ①Stainless steel 304 ②Stainless steel 316 (For brackish water or customer requirements ) |
3 | Iron and manganese removal filter | Before/after the quartz sand filter, It mainly depends on the raw water impurities | Φ250×H1400 Φ330×H1400 Φ600×H1900 | ①Fiber Reinforced Plastic ②Stainless steel SUS-304 SUS-316 |
4 | Sand filter | To remove large particulate matter, suspended solids, dust, sediment, algae, etc. in the water (rough sand at the bottom, fine sand in the middle) | Φ250×H1400 Φ330×H1400 Φ600×H1900 | ①Fiber Reinforced Plastic ②Stainless steel SUS-304 SUS-316 ③Carbon steel |
5 | Carbon filter | Remove residual chlorine, organic matter, taste, bacteria in the water, and reduce the turbidity of the water (coarse sand at the bottom, activated carbon in the middle) | Φ250×H1400 Φ330×H1400 Φ600×H1900 | ①Fiber Reinforced Plastic ②Stainless steel SUS-304 SUS-316 |
6 | Water softener | Let the cation resin adsorb Ca2+ and Mg2+ions in the water (the "scale" that produces precipitation), reduce the hardness in the water, and prevent the scale from precipitating in pipes, containers, boilers and other equipment | Φ250×H1400 Φ330×H1400 Φ600×H1900 | ①Fiber Reinforced Plastic ②Stainless steel SUS-304 SUS-316 |
7 | Precision Filter | It can intercept and remove impurity particles with a particle size greater than 5μm (5μm for conventional filter elements, minimum 1μm) | 10“×5μm 20“×5μm 30“×5μm 40“×5μm | ①U-PVC Fiber Reinforced Plastic ②Stainless steel SUS-304 SUS-316 |
8 | High-pressure pump | To provide pressure for reverse osmosis systems | GRUNDFOS CNP | Stainless steel SUS-304 SUS-316 |
9 | Reverse Osmosis System | Mainly remove TDS in water, but also remove bacteria, viruses and other harmful substances | DuPont Vontron Toray Hydranaut | ①Fiber Reinforced Plastic ②Stainless steel SUS-304 SUS-316 |
10 | Pure water tank | ①To store pure water | 0.25m³~50m³ | ①PE ②Fiber Reinforced Plastic ③Stainless steel SUS-304 SUS-316 ④Carbon steel |
Regular Replacement of Water Treatment Consumables:
To ensure the ongoing performance and water quality of your water treatment system, several consumables require periodic replacement. Here are the recommended replacement intervals for key components:
Quartz Sand: This material, used in sand filters, should be replaced approximately every 18-24 months to maintain filtration effectiveness.
Activated Carbon: Vital for removing impurities and improving taste, activated carbon should be replaced every 18-24 months to ensure its adsorptive capacity is not exhausted.
Resin: Used in ion exchange processes, resin should be replaced every 18-24 months to keep the system's ability to remove ions and prevent scale buildup.
PP Filter Cartridge: These cartridges, which are essential for preliminary filtration, need to be replaced more frequently—approximately every month—to ensure optimal filtration and prevent clogging.
RO Membrane: The reverse osmosis membrane, a critical component for removing contaminants, should be replaced every 2 years to maintain high purification rates.
Recommendation for PP Filter Cartridges: Given the monthly replacement requirement for PP filter cartridges, we advise purchasing 1 to 2 years' worth of these cartridges when you acquire the machine. This proactive purchase helps to avoid supply interruptions and ensures that your system can operate without delay.
Treated water:
Power industry: | boiler water |
Electronics industry: | semiconductor industry ultra pure water. integrated circuit cleaning water. |
Beverage industry: | formulation of water, production water, washing water. |
Pharmaceutical industry: | process water, reagent water, washing water, water injection, drug concentration and separation. |
Chemical industry: | the production of water, waste water treatment, the value of the separation of substances. |
Drinking water project: | the preparation of pure water, drinking water purification. |
Petroleum and chemical industry: | advanced treatment of oilfield injected water and petrochemical wastewater. |
Sea water desalination: | Sea Island, coastal water shortage areas. ships, sea water and other production and living water. |
Company Information
Guangzhou KaiYuan Water Treatment Equipment Co.,Ltd was established in 2008. It is executive director unit of China Water Enterprises Confederation Desalination Branch and member of MIAC(China Membrane Industry Association). Our company is IS09001:2015 certified company andour products are approved CE and SGS. We are 16 years full experience in pure water treatment equipment manufacturer.
We has been engaged in water treatment product and technology development and utilization. We are specialized in manufacturing reverse osmosis(RO)system seawater desalination system, ultrapure water system, pure water system for GMP medical andpharmaceutical, Nanofiltration system(NF), Ultrafiltration system(UF), Micron filtration system(MF), lon exchange system, EDl systems etc. We can provide water treatment project design, manufacture, installation and all-round service.
Welcome customers from all over the world to visit us.Our products are sold well not only in domestic, but also in morethan 90 countries all over the world.
Our product range including industrial and commercial Reverse Osmosis Water Treatment System, Brackish Water Desalination Plant, Seawater Desalination Machine, River Water Filtration Systems, Underground Water Purification Equipment, Well Water Filtration Systems, Borehole Water Purification Systems, Electrodeionization EDI Water Treatment Systems, Ion Exchange Water Treatment System, Ultrafiltration UF Membrane Systems, and also our own production for stainless steel water treatment equipments such as Water Storage Tank, Water Filter Tanks, Cartridge Filter Housing, Bag Filter Housing, Mechanical Filter Tanks, Pressure Vessel, Hot Water Storage Tanks, Sand Filter Tanks, Carbon Filter Tanks, Water Softener Tanks…..etc. and all of them fix for our client’application and budget in water treatment industry.
Input Your Owned Water, Output Your Needed Water
Build win-win relationship with client, staff and supplier.
Delivery time: Around 1-7 working days for small machine, 15-45 working days for big machine (depending on raw material availability)
Export standard packing: Carton/wooden case (plywood), no fumigation required, suitable for shipping.
Manuals: We offer comprehensive manuals in both paper and electronic formats to assist with the operation and maintenance of the machine.
Assembly and Protection: The machine is assembled with care and shipped in a manner that ensures its safety during transit. It is wrapped with protective film to prevent any wear or damage to the equipment.
Packaging and After-Sales Service:
Packaging: We use wooden case packaging to safeguard the machine during shipping, providing additional protection against potential damage.
After-Sales Service: We offer a one-year after-sales service warranty to ensure customer satisfaction and to address any issues that may arise post-purchase.
Factory Dispatch: The goods are carefully loaded into containers at the factory and dispatched to ensure they reach you in a timely and secure manner.
Our customer base is truly global, with clients located in over 120 countries across Europe, Africa, the Middle East, and Asia, as well as other parts of the world.
Our products are exported not only to South America and North America but also serve more than 2,000 domestic customers, showcasing the widespread reach and acceptance of our offerings.
Our Dedicated Team and Services
At our company, a team of highly skilled engineers is dedicated to the entire lifecycle of our water treatment equipment, from development and manufacturing to installation and debugging. We offer international sales support that is available for contact at any time, ensuring seamless communication with our global clientele.
Quality Assurance and Certifications
We maintain rigorous quality control standards. Our products are certified by CE and SGS, ensuring they meet international safety and performance standards. Additionally, we provide dedicated customer service through our hotline, ready to address any inquiries or concerns promptly.
Customized Solutions and OEM/ODM Services
Our professional engineers are equipped to provide tailored plans based on specific customer requirements. We offer OEM (Original Equipment Manufacturer) and ODM (Original Design Manufacturer) services, allowing us to create customized solutions that meet the unique needs of our clients.
Expertise and Experience
We boast a team of over 20 engineers, each with more than 8 years of experience in the field. They specialize in designing various treatment processes tailored to the customer's raw water quality and desired output water specifications. Our pipe connection technology adheres to high medical standards, reflecting our commitment to excellence.
Global Installation Support
Our engineers are capable of providing global installation support, ensuring that our machines are set up correctly and efficiently, regardless of the customer's location.
OEM/ODM Professional Team and Technical Support
We pride ourselves on being a 100% OEM/ODM professional team. To further support our customers, we offer free lifetime technical support, ensuring that you have access to expert assistance whenever needed.
FAQ
Q: What is the guarantee and after-sale service that Kai Yuan Company can provide?
A: It is a one-year guarantee (except for damage caused by human error).
Any issues with accessories, such as valves, pumps, etc., within one year, we can deliver replacements to you for free.
Q. Is the machine/equipment difficult to install?
A: At Kai Yuan factory, we take pride in ensuring that every machine is thoroughly connected and adjusted to optimal performance standards before it leaves our facility. This meticulous pre-delivery process guarantees that our customers receive a system that is ready for immediate use.
To further assist our customers, we provide a comprehensive "User Manual" that covers the entire system. This manual serves as an invaluable guide, detailing the operation, maintenance, and troubleshooting of the equipment.
Additionally, recognizing that visual instruction can be highly beneficial, we are pleased to offer a video tutorial on machine operation upon request. This video serves as a practical supplement to the user manual, offering step-by-step visual guidance for operating the machine effectively.
Q. Will Kai Yuan help customers install the machine in their country?
A: Additionally, Kai Yuan can send engineers to the customer's location to install the equipment and train staff, but the buyer must cover the relevant costs for our workers.
Q. How is the machine packed? Is it suitable for shipment?
A: The machine will be packed in a standard wooden case, making it suitable for shipment. After you receive the machine, you can open the wooden case to remove the machine.
Q. What information do I need to provide to obtain the suitable RO machine or other relevant products I want?
A: It would be helpful if you could provide us with a raw water analysis or water test report.
